SCREW-IN CARTRIDGE VALVE OD113118A000000-VED-016-NC-08A-A-31-0000
1009441
På lager
Information
| Cavity | CA-08A-2N |
| Coil | D36 |
| Coil integrated | To be ordered separately |
| Direct - Pilot | Direct acting |
| Hydraulic fluid | HL;HLP |
| Iteration | 5 |
| Long Description | Maximum flow 15 l/min (4 gpm)Maximum operating pressure 250 bar (3600 psi)Cavity CA-08A-2NScrew-in cartridge valve |
| Max. flow | 15 l/min |
| Max. pressure | 250 bar |
| Nominal flow | 15 l/min |
| Normal position | Normally closed |
| Ports number | 2 |
| Positions | 2 |
| Product family classification | Solenoid operated valves direct acting poppet type 2-way double lock |
| Product family type | VED |
| Sealing material | NBR |
| Short Description | SCREW-IN CARTRIDGE VALVE OD113118A000000-VED-016-NC-08A-A-31-0000 |
| Spool Poppet | Poppet type |
| Type of actuation | Solenoid-actuated on/off |
| Type of connection | Screw-in cartridge valve |
| Weight | 0.12 kg |
