SCREW-IN CARTRIDGE VALVE OD150636B000000-VEI-016-NO-10A-B-06-0000
4010320
På lager
Information
| Cavity | CA-10A-2N |
| Coil | D36 |
| Coil integrated | To be ordered separately |
| Direct - Pilot | Pilot operated |
| Hydraulic fluid | HL;HLP |
| Iteration | 5 |
| Long Description | Maximum flow 70 l/min (19 gpm)Cavity CA-10A-2NScrew-in cartridge valveMaximum operating pressure 350 bar (5000 psi) |
| Manual override | Push manual override |
| Max. flow | 70 l/min |
| Max. pressure | 350 bar |
| Nominal flow | 70 l/min |
| Normal position | Normally open |
| Ports number | 2 |
| Positions | 2 |
| Product family classification | Solenoid operated valves pilot operated poppet type 2-way |
| Product family type | VEI |
| Sealing material | NBR |
| Short Description | SCREW-IN CARTRIDGE VALVE OD150636B000000-VEI-016-NO-10A-B-06-0000 |
| Spool Poppet | Poppet type |
| Type of actuation | Solenoid-actuated on/off |
| Type of connection | Screw-in cartridge valve |
| Weight | 0.18 kg |
