VALVE AMPLIFIER VT-MSPA1-2X/A5/000/000
8234-R901439034
Udsolgt
Information
| Conformity | CE |
| Conformity description | CE – electromagnetic compatibility 2014/30/EU |
| Connectivity | Analog, command value 0 … 10 V |
| Design | Module |
| Electrical connection description | Screw terminals |
| Electrical connector | Screw terminals |
| Iteration | 6 |
| Long Description | Characteristic curves of the Rexroth valves stored in the device. Valve optimization via push-buttons. Diagnosis: LED status and measuring sockets for parameters, command values and actual values. Ramp generators can be set separately.Communication: Command value input 0 ... 10 VInstallation on DIN rail |
| Short Description | VALVE AMPLIFIER VT-MSPA1-2X/A5/000/000 |
| Supply voltage | 24 VDC |
| Weight | 0.28 kg |
