SHUTTLE VALVE MHSU 3 KA1X/420
R901071225
Information
| Cavity | M10x1 |
| Direct - Pilot | Direct acting |
| Hydraulic fluid | HL;HLP;HEES;HEPG |
| Iteration | 11 |
| Long Description | Maximum operating pressure 420 bar (6000 psi)Maximum flow 10 l/min (3 gpm)Cavity M10x1Screw-in cartridge valve for insertion |
| Max. flow | 10 l/min |
| Max. pressure | 420 bar |
| Nominal flow | 10 l/min |
| Ports number | 3 |
| Product family classification | Shuttle valve |
| Product family type | MHSU |
| Sealing material | FKM |
| Short Description | SHUTTLE VALVE MHSU 3 KA1X/420 |
| Weight | 0.0072 kg |
