DIRECTIONAL SPOOL VALVE KKDER1EA/HN0V
R901070123
Udsolgt
Information
| Cavity | Sun T-31A |
| Coil | GZ37 |
| Coil integrated | To be ordered separately |
| Direct - Pilot | Direct acting |
| Hydraulic fluid | HL;HLP;HETG;HEES;HEPG |
| Iteration | 11 |
| Long Description | Maximum flow 40 l/min (11 gpm)Cavity Sun T-31AScrew-in cartridge valveMaximum operating pressure 350 bar (5000 psi) |
| Max. flow | 40 l/min |
| Max. pressure | 350 bar |
| Nominal flow | 40 l/min |
| Ports number | 4 |
| Positions | 2 |
| Product family classification | 4/2 directional spool valve, direct operated with solenoid actuation |
| Product family type | KKDE |
| Sealing material | FKM |
| Short Description | DIRECTIONAL SPOOL VALVE KKDER1EA/HN0V |
| Spool Poppet | Spool type |
| Type of actuation | Solenoid-actuated on/off |
| Type of connection | Screw-in cartridge valve |
| Weight | 0.34 kg |
