PRESSURE REDUCING VALVE KRD2L2AB/LV
R901082849
Udsolgt
Information
| Adjustment options | Threaded pin with hexagon and protective cap |
| Cavity | R/ISO 7789-27-01-1-89 |
| Direct - Pilot | Direct acting |
| Hydraulic fluid | HL;HLP;HEES;HEPG |
| Iteration | 10 |
| Long Description | Maximum flow 25 l/min (7 gpm)Maximum operating pressure 400 bar (5800 psi)Cavity R/ISO 7789-27-01-1-89Screw-in cartridge valve |
| Max. flow | 25 l/min |
| Max. pressure | 400 bar |
| Nominal flow | 25 l/min |
| Normal position | Normally open |
| Ports number | 2 |
| Pressure pre-setting | Without pressure pre-setting |
| Product family classification | 2-way pressure reducing valve, direct operated |
| Product family type | KRD |
| Sealing material | FKM |
| Short Description | PRESSURE REDUCING VALVE KRD2L2AB/LV |
| Spool Poppet | Poppet type |
| Type of connection | Screw-in cartridge valve |
| Weight | 0.7942 kg |
