DIRECTIONAL-CONTROL VALVE L7002A03AI00000-KS.VS70-1/4G-A-A-DI-N
R930059682
Udsolgt
Information
| Coil | D36 |
| Coil integrated | To be ordered separately |
| Direct - Pilot | Direct acting |
| Drain type | Internal drain |
| Hydraulic fluid | HL;HLP |
| Iteration | 5 |
| Long Description | Size 4Maximum flow 20 l/min (5 gpm)Ports: G 1/4Maximum operating pressure 310 bar (4495 psi) |
| Max. flow | 20 l/min |
| Max. pressure | 310 bar |
| Nominal flow | 20 l/min |
| Ports | G 1/4 |
| Ports number | 3 |
| Positions | 2 |
| Product family classification | 3/2 ways/positions flow diverters |
| Product family type | VS70 |
| Sealing material | NBR |
| Short Description | DIRECTIONAL-CONTROL VALVE L7002A03AI00000-KS.VS70-1/4G-A-A-DI-N |
| Spool Poppet | Spool type |
| Type of actuation | Solenoid-actuated on/off |
| Type of connection | Threaded connection |
| Weight | 0.67 kg |
