SOL PROP VALVE 2WAY(LOW VAR.)
JP02C2000VL
Udsolgt
Information
| Afdeling | Hydraulic Cartridge Systems Division |
| Aktiveringstype | Electrical |
| Aktiveringstype | Electrical |
| Betjeningstype | Solenoid operated |
| Body materiale | N/A |
| Bypassfunktionalitet | N/A |
| Driftstemperatur | -15 to +400 �F |
| Filters effektivitetsklassificering | ISO 4406 18/16/13, SAE Class 4 |
| Flowhastighed | 7.5 L/min |
| Flowhastighed | 2 GAL/MIN, 7.5 L/MIN |
| Flowhastighed - nøjagtighed | +/- 7% |
| Flowretning | Top to Side (3 - 2) |
| For væsketype | Mineral-based or synthetic hydraulic fluids |
| Forbindelsestype | N/A |
| Form størrelse | C08-3 |
| Frekvens | 100-400 Hz |
| Funktion | Proportional Flow Control/Regulator |
| Hysterese | < 10% |
| Installationsmoment | 20 lb-ft |
| Konfiguration | Normally Closed, Pressure Compensated |
| Konfiguration | Normally Closed, Pressure Compensated |
| Lækagehastighed | 570 @ 3000 PSI (210 BAR) cm3/min |
| Maks. driftstemperatur | +204 �C |
| Maks. driftstryk | 210 bar |
| Maks. flowhastighed | 2.0 Gal/min |
| Maksimal kinematisk viskositet | 45-2000 SSU (6 to 420 cSt) |
| Maksimalt indløbstryktrin | 210 bar |
| Mindste driftstemperatur | -26 �C |
| Mindste trykdifferens | 10.3 bar |
| Pakningsmateriale | Fluorocarbon |
| Pakningsmateriale | Fluorocarbon |
| partId (right) | 2436861 |
| Spolemøtriks tilspændingsmoment | 3 lb-ft |
| Spoletype | 1/2" Super Coil Low Watt (CCS) |
| Strøm | Max: 1.15 @ 12 VDC, 0.58 @ 24 VDC A |
| Strømforbrug | 14 W |
| Tilslutningsstørrelse | N/A |
| Trådmaskesigte medfølger | No |
| Variation af lukkepunkt | N/A |
| Variation af åbningspunkt | 25% of Input Signal |
| Ventilmateriale | All parts steel. All operating parts hardened steel |
| Vægt | 0.08 kg |
